60*150 mm TSK type for long travel distance heavy duty wide width nylon aluminum frame cable carrier

Short Description:

1, The TSK series of cable carrier is a kind of heavy duty and long travle distance cable carrier. The frame material is aluminum alloy, so that enabled it to extend for width at the diemension customer needed.

2. Material: Boty: Reinforced Nylon PA6, PA66 ; frame: aluminum alloy.

3. Size: Inner size: Height*width, 60*150 mm

4. Plenty of moulds for various sizes to choose. Also difference types, models. We can make new mould for special requirements.

5, The raw material: Original new nylon raw material. We don’t use recycling materials, which is cheap but week in physical performance.

6, Operation and maintenance: Easy. We keep modifying and improving our moulds’ structures according to the feedback of our customers after usage. And always paying much attention to function.






PDF Download
Details
Tags

Product Video



Structure feature

1, The TSK series of cable carrier is a kind of heavy duty and long travle distance cable carrier. The frame material is aluminum alloy, so that enabled it to extend for width at the diemension customer needed.

2. Material: Boty: Reinforced Nylon PA6, PA66 ; frame: aluminum alloy.

3. Size: Inner size: Height*width, 60*150 mm

4. Plenty of moulds for various sizes to choose. Also difference types, models. We can make new mould for special requirements.

5, The raw material: Original new nylon raw material. We don’t use recycling materials, which is cheap but week in physical performance.

6, Operation and maintenance: Easy. We keep modifying and improving our moulds’ structures according to the feedback of our customers after usage. And always paying much attention to function.

Product Name Reinforced nylon cable chain
Material PA6, PA66
Color Black
Standard DIN GB ISO JIS BA ANSI
Working temperature -40-130 ℃
Recommended gap 10%
Features wearable, elastic, fire proof, self-lubricating.
Open side Both side.

TSK 60*150 measurement

Dimension 1
Dimension 3
Dimension 2
Dimension 4

Structures

drawing 1
drawing 2

drawing 4

Series Dimension

TYPE

Inner dimensions

Height*Width

Outer dimensions

Height*Width

Radius

Pitch

Pitch/meter

Weight Kg

TSK50



50*50-200



R120
R150
R200
R250
R300



75

12



50*200-400









TSK60



60*50-100



R100
R150
R200
R250
R300



84

12



60*100-150









TSK68







68*50-100



R200
R250
R300
R350
R390







100







10









68*100-150





68*150-200

113*249

5.5KG

68*250





TSK disassembling

Disassebmling 1
Disassebmling 2
Disassebmling 3
Disassebmling 4
Disassebmling 5

Production flow

未标题-3

How to identify good products

identify 1
identify 2
identify 3
how to identify 4
