50*100 mm VMTM type aluminum alloy plate nylon enclosed energy chain

Short Description:

1. Grade: Reinforced Nylon PA6, PA66

2. Size: Inner size: Height*width, 50*100 mm

3. Plenty of moulds for various sizes to choose. Also difference types, models. We can make new mould for special requirements.

4, The raw material: Original new nylon raw material. We don’t use recycling materials, which is cheap but week in physical performance. The covering plate is aluminum alloy, it got more strength in protection than the nylon cover. It is better to be used in the condition with various kinds of friction or collision.

5, Operation and maintenance: Easy. We keep modifying and improving our moulds’ structures according to the feedback of our customers after usage. And always paying much attention to function.






PDF Download
Details
Tags

structure feature

1. Grade: Reinforced Nylon PA6, PA66

2. Size: Inner size: Height*width, 50*100 mm

3. Plenty of moulds for various sizes to choose. Also difference types, models. We can make new mould for special requirements.

4, The raw material: Original new nylon raw material. We don’t use recycling materials, which is cheap but week in physical performance. The covering plate is aluminum alloy, it got more strength in protection than the nylon cover. It is better to be used in the condition with various kinds of friction or collision.

5, Operation and maintenance: Easy. We keep modifying and improving our moulds’ structures according to the feedback of our customers after usage. And always paying much attention to function.

Product Name Reinforced nylon-aluminum cable chain
Material PA6, PA66
Color Black and silver
Standard DIN GB ISO JIS BA ANSI
Working temperature -40-130 ℃
Recommended gap 10%
Features wearable, elastic, fire proof, self-lubricating.
Open side Both side.

VMTM 50*100 measurement

Dimension 1
Dimension 2
Dimension 3
Dimension 4

Structures

drawing 1 拷贝
Length caculation
section drawing
Load chart

Series Dimension

TYPE Inner dimensions Height*Width Outter dimensions Height*Width Radius Pitch Pitch/meter Weight Kg
VMTM35 35*80F 55*108 R115 58 15 2.6
VMTM50 50*100F 74*131 R135 75 14 4.9
VMTM68 67*200 98*238 R200/R250/R300 /R350/R500 100 6 4.8
